Gregg Elementary - LEED Profile

    • pic1
    • pic2
    • pic3
    • pic4
    • pic5

Project Description

  • The new Gregg Elementary School replacement is an 84,704-square-foot, single-story, free-standing elementary school for 750 students from pre-kindergarten through fifth grade. The new school replaces a 50-year-old elementary school (now demolished) that had 55,000 square feet and occupied an urban site of 7.8+ acres surrounded by single-family homes, a neighborhood park and light-industrial manufacturing facilities. Grade levels are organized into “wings” and in proximity to all grade level wings are laboratories for art, computer and science. The staff offices serve as the primary point of secure entry into the facility. The school has a full-service kitchen and auditorium-dining spaces, also in close proximity to other functions.
  • LEED - Sustainable Overview
    Sustainable Overview
    • Selection of interior and exterior materials recall the context of the neighborhood and fulfill benchmarks for materials: regional manufacturing, recycled materials, “renew-ability,” low or no chemical odors, and creativity in development
    • Provided enhanced acoustics within gathering spaces
    • Protected site amenities and mature trees
    • An environmentally responsible, economically responsible, and user-responsible facility
  • LEED - Water Efficiency
    Water Efficiency
    • Maximize water efficiency inside and outside through the use of low-flow plumbing fixtures, proximity sensors, and high-efficiency irrigation controllers
  • LEED - Energy & Atmosphere
    Energy & Atmosphere
    • Management of construction process to recycle construction debris
    • Curriculum created to utilize LEED process and school building as a teaching tool for the students
  • LEED - Materials & Resources
    Materials & Resources
    • Ceilings are predominantly acoustic ceiling tile
    • Site paving is concrete – an HISD standard – for durability
  • LEED - Indoor Environmental Air Quality
    Indoor Environmental Air Quality
    • Air-cooled chillers with individual variable air volume (VAV) boxes; 2-pipe system with electric re-heat in the main building
    • Mechanical ducts kept clean during construction and flushed-out prior to occupancy
    • The cafetorium and library have a 4-pipe system for cooling and heating
    • Interior finished flooring is a combination of vinyl composition tile (VCT), carpet tiles, and terrazzo
    • Use of construction materials with low Volatile Organic Compounds (VOC) along with lighting, enhanced commissioning of the mechanical and energy systems, HVAC controls, and the CO2 level monitoring
  • LEED - Innovation in Design
    Innovation in Design
    • One-story steel-frame structure over a concrete slab with drilled and under-reamed concrete piers
  • Achievements

    26%
    reduction in energy consumption
    40%
    reduction in water use
    30%
    recycled content of materials
    27%
    use of local/regional materials
    90%
    construction waste diverted from landfill
  • LEED® Facts

    LEED® for Schools (v2007)

    Certification awarded Apr 2012

    Silver
    39*
    Sustainable Sites
    6/16
    Water Efficiency
    4/7
    Energy & Atmosphere
    8/17
    Materials & Resources
    5/13
    Indoor Environmental Quality
    10/19
    Innovation
    6/6

    * Out of a possible 78 points

  • Project Information
    • Owner: Houston Independent School District (HISD)
    • Address: 6701 Roxbury Rd, Houston, TX 77087
    • Architect: Hermes Architects
    • Civil Engineer: Sunland Group
    • MEP Engineer: Bovay Engineers, Inc.
    • Structural Engineer: Matrix Structural Engineers
    • Commissioning Agent: Redding, Linden, Burr, Inc.
    • Contractor: Anslow Bryant Construction, Ltd.
    • Project Size: 84,704 SF
    • Project Budget: $16,603,500
    • Opened: December 2011

LEED Document

  • About LEED®
    The LEED® (Leadership in Energy & Environmental Design) Green Building Rating System is the national benchmark for the design, construction, and operations of high-performance green buildings. Visit the U.S.Green Building Council’s Web site at www.usgbc.org to learn more about how you can make LEED® work for you.
